Products Description

Surface thermocouple is used to measure static surface temperature of industries related to forging, hot pressing, partial heat,electrical crankshaft tile,plastic injecting machine,metalic quenching, mould processing ranging 0~800°C which is portable, intuitivism, fast response, cheaper cost.

1. Application

It is widely used to measure surface temperature of steam trubine, axle bush of motor in power plant or other machine body related to Textile dyeing, papermaking, plastic, rubber, ceramic, alumninum alloy

2. Feature

1)Short thermal response time, narrow dynamic deviation.

2)Bendable to fix.

3)Wide measuring range

4)High mechanical strength, good pressure-resisting.

3. Technical specifications

Calibration: K type

I class or II class

Dia:6mm or 8mm

Material:SUS304 or 310S

Application:Al liquid 800C

Probe length:1000mm(can be customized)

Wire length:1mts

Connector:Yellow mini plug

specifications

● 5 digits display
● Test accuracy: 0.1 °C & 0.1 °F
● Adjust calibration or restore to factory default settings
● Low battery indicator
● 2 way temperature testing (T1 & T2)
● Measure separately (T1 - T2)
● Extra two metal probe °C, °F & K (switch)
● Temperature range: -50 ~ 1300 °C (-58 ~ 2372 °F)
● Accuracy: ±0.1 °C ± 0.4
● Working temperature: 0 ~ 40 °C (32 ~ 104 °F)
● Working humidity: 0 ~ 70 % (R.H.)
● Current: One K-type: approx DC 2.8mA( typical) / Two K-type: approx. DC 3mA(typical)
● Unit: °C or °F
● 60V DC or 24V AC maximum input voltage on any combination input pins
● Reading frequency: 2.5 times per second
● Accept standard miniature thermocouple connectors
● Powered by standard 9V battery (included)
● Size: 16*7.8*4.2 cm

How to use surface temperature thermometer

1. Install the 9V battery ;

2. Connect the probe to thermometer;

3. Put the other end on the target item;

4. Read the data on the screen.

Application Scenarios

With core advantages of "precision, speed, portability, ease of use, and multi-scenario adaptation", this product is widely used in industrial production, civil life, scientific research experiments and other scenarios that require measuring the surface temperature of objects, mainly including:

Industrial Manufacturing Industry: Temperature detection of mechanical parts, equipment housings, and pipeline surfaces to determine if the equipment is overheated; surface temperature monitoring of weldments and heat-treated workpieces to ensure process quality.

Electronics and Electrical Appliance Industry: Temperature rise testing of electronic product housings, circuit boards, and battery surfaces; temperature detection of home appliance (air conditioner, refrigerator, oven) housings and heating components to ensure safe use.

Construction and HVAC Industry: Surface temperature measurement of walls, floors, and radiators to judge heating effect; surface temperature detection of pipelines and insulation layers to identify heat loss.

Automotive Industry: Temperature detection of automotive engine blocks, exhaust pipes, and tire surfaces; temperature rise testing of new energy vehicle battery packs and motor housings.

Food and Pharmaceutical Industry: Surface temperature monitoring of food processing equipment (ovens, frying pans); temperature detection of drug storage environments and sterilization equipment surfaces to ensure product safety.

Scientific Research and Experiment Scenarios: Surface thermal performance testing of materials in universities and research institutions; surface temperature monitoring of small experimental equipment to support experimental data.

Civil Life Scenarios: Surface temperature measurement in scenarios such as home heating, home appliance maintenance, and floor heating installation and commissioning, with simple operation to meet daily use needs.

Product Advantages

Precise and Efficient with Reliable Data: ±1% FS high precision + ≤500ms fast response, compared with ordinary surface thermometers, it has higher temperature measurement accuracy and faster speed, providing a reliable basis for decision-making.

Multi-probe Adaptation with Practical Flexibility: Multiple probes such as magnetic and leaf spring types are available, which can adapt to different types of measured surfaces (flat, curved, metal, non-metal) with closer contact and more accurate temperature measurement.

Portable and Easy to Use with Simple Operation: Compact and lightweight, easy to hold with one hand, 1.5m wire facilitates long-distance measurement; one-key operation + clear display, no professional knowledge required, ordinary people can use it easily.

Durable and Easy to Maintain with Low Cost: IP54 protection + high-quality materials, wear-resistant, waterproof and dustproof; long battery life design reduces battery replacement frequency, later maintenance only requires battery replacement with extremely low cost.

High Cost-effectiveness with Wide Scene Coverage: Balancing industrial-grade precision and civil-grade ease of use, one device can meet multiple needs such as industrial production, daily maintenance, and scientific research experiments, no need to purchase special equipment separately.

Frequently Asked Questions

Will the accuracy be affected when measuring surfaces of different materials (metal/non-metal)?

Answer: There will be a slight impact, but it is within the allowable error range. Metal surfaces have fast thermal conductivity, resulting in more accurate temperature measurement; non-metal surfaces (such as plastic and wood) have slow thermal conductivity. It is recommended to select a leaf spring probe to increase the contact area or extend the contact time (1~2 seconds) to ensure sufficient temperature conduction and reduce errors.

Can the probe wire be extended to more than 5m?

Answer: Yes. The standard wire is 1.5m, which can be customized to 5m or 10m, but shielded high-temperature resistant wire must be used to avoid signal attenuation and electromagnetic interference; the response time may increase slightly after extension (≤800ms), which does not affect normal use.

What if the display backlight does not turn on?

Answer: ① Check if the battery power is sufficient; the backlight will be automatically turned off when the power is too low; ② Try to wake up the backlight by pressing the operation button (the backlight of some models is trigger-type, which is turned on by pressing the button); ③ If it still does not turn on, there may be a fault in the backlight function, and you need to contact the manufacturer for maintenance.

What precautions should be taken when measuring high-temperature surfaces (such as 500℃)?

Answer: ① Select a high-temperature resistant probe (confirm that the probe temperature resistance ≥ measured temperature) to avoid probe damage; ② Do not contact the high-temperature surface for a long time (single measurement does not exceed 30 seconds) to prevent wire or probe aging; ③ Wear protective gloves during operation to avoid scalding.

Why does the data fluctuate greatly during measurement?

Answer: ① The probe is not in close contact with the measured surface, and it needs to be reattached (ensure the magnetic probe is firmly adsorbed, and the leaf spring probe is tightly pressed); ② The temperature of the measured surface itself is dynamically changing, and the "data hold" function can be turned on to lock the measured value; ③ Environmental air flow interference, and the air flow can be blocked before measurement again.

Does the product need regular calibration?

Answer: It is recommended to calibrate once a year. After long-term use or measurement in high-temperature and corrosive environments, the accuracy may deviate. Calibration can be performed through standard constant temperature baths or professional calibration equipment to ensure measurement accuracy; if the use frequency is low, the calibration interval can be extended to 2 years.
