Features

I. Core Parameters

Parameter Category	Specific Specifications / Parameter Values
Product Model	WRP-100
Thermocouple Grade	Type S (Platinum-Rhodium 10 - Platinum)
Operating Temperature Range	0~1500℃ (commonly used 0~1300℃; 99% alumina protection tube is required for temperatures above 1300℃)
Protection Tube Material	99% alumina (Al₂O₃); 310S (2520) optional for oxidizing environment above 900℃; GH3039, Inconel 600 optional for temperatures above 1000℃
Protection Tube Dimensions	Diameter and length are customizable
Electrode Material	Positive electrode: Platinum-rhodium alloy; Negative electrode: High-purity platinum (precious metal material)
Installation & Connection Method	Non-sealed environment: Threadless / Flangeless; Sealed environment: With thread / With flange (customizable to equipment requirements)
Applicable Equipment	Laboratory muffle furnace, powder metallurgy furnace, bright sintering furnace, vacuum furnace, melting furnace, etc.

II. Product Features

Accurate High-Temperature Measurement: Adopts Type S (Platinum-Rhodium 10 - Platinum) precious metal electrodes, with a temperature measurement range of 0~1500℃. It maintains stable measurement accuracy even in high-temperature environments, meeting the requirements of precision high-temperature processes.

Strong Adaptability of Protection Materials: The protection tube defaults to 99% alumina, which is high-temperature resistant and chemical corrosion resistant, and can work stably in high-temperature scenarios above 1300℃. Materials such as 310S and Inconel 600 can be switched according to temperature and environmental requirements, adapting to different oxidizing environments.

Flexible Installation and Adaptation: Supports installation in sealed and non-sealed environments, with customizable thread or flange connection methods. It can accurately match the installation requirements of different types of high-temperature furnaces, featuring strong compatibility.

Specialized Application Scenarios: Specifically designed for laboratory and industrial high-temperature furnaces, it is compatible with equipment such as muffle furnaces, vacuum furnaces, and melting furnaces, and can directly measure the temperature of gases, liquids, melts, and solid surfaces.

Wide Compatibility: Can be used with display instruments, recorders, or computers, with stable data transmission, adapting to various industrial measurement and control systems.

III. Application Scenarios

With the core advantage of precious metal high-temperature measurement, this product is mainly applied in the following scenarios:

Laboratory Scenarios: Temperature monitoring of laboratory muffle furnaces, providing accurate high-temperature data for material analysis, chemical experiments, etc.

Powder Metallurgy Industry: Temperature control of powder metallurgy sintering furnaces, ensuring temperature stability during metal powder sintering and improving product density.

Industrial High-Temperature Furnace Measurement: Temperature measurement of equipment such as bright sintering furnaces, vacuum furnaces, and melting furnaces, directly monitoring the temperature of gases, melts, or workpiece surfaces in the furnace.

Refractory Material Testing: Temperature measurement of various refractory material high-temperature performance testing equipment, adapting to scenarios such as refractory sintering and high-temperature resistance experiments.

High-End Manufacturing Field: Temperature control and monitoring of high-temperature heat treatment processes in high-end manufacturing such as aerospace and electronic components.

IV. Frequently Asked Questions (FAQs)

How to choose different protection tube materials?

Answer: For oxidizing environments below 900℃, conventional 99% alumina tubes can be selected; For oxidizing environments above 900℃, 310S (2520) is selected; For temperatures above 1000℃, GH3039 or Inconel 600 is selected; For high-temperature scenarios above 1300℃, 99% alumina tubes must be used to meet the high-temperature resistance requirements.

What is the difference between installation in sealed and non-sealed environments?

Answer: For sealed environments, thread or flange connection methods must be used to ensure no gas leakage in the furnace and prevent the external environment from affecting temperature measurement; For non-sealed environments, direct installation is possible without additional sealing accessories, making the installation more convenient.

Is regular calibration required during the use of the product?

Answer: Yes. Annual calibration is recommended, especially under working conditions of long-term high-temperature use or frequent start-stop. Regular calibration can ensure measurement accuracy and avoid increased errors caused by electrode aging.

What are the advantages of this product compared with ordinary metal thermocouples (such as Type K)?

Answer: The core advantages lie in high-temperature performance and stability: Type K thermocouples have a maximum temperature resistance of about 1200℃, and are prone to oxidation and accuracy drift at high temperatures; Type WRP-100 platinum-rhodium thermocouples have a temperature resistance of up to 1500℃, and the precious metal material has strong oxidation resistance and stable thermoelectric potential, making it suitable for high-temperature scenarios with high requirements for measurement accuracy.
