Tungsten Rhenium Ceramic Thermocouple

Tungsten-rhenium thermocouple is currently the highest temperature-measuring thermocouple. Its major usage is to measure temperature in vacuum, hydrogen, and inert atmosphere. The maximum measuring temperature reaches 2500℃. There are C, D, and A types have been specified. Our tungsten-rhenium thermocouples are made of specialized molybdenum, tantalum, tungsten, and corundum protective tubes which are filled with insulators, and assembled together under a vacuum or protective atmosphere with a seal. In real-world long-term use cases, it can reach a max measuring temperature of 2000℃, and withstand 10MPa pressure. The two-layer Molybdenum and Corundum tube could be used for temperature measurement in an oxidizing atmosphere and could replace the use of expensive noble-metal thermocouples.

Duchin promoted tungsten-rhenium thermocouple in 1997,participating in customized national standards "tungsten-rhenium thermocouples wire and indexing table "and industry standards"tungsten-rhenium thermocouples technical conditions",applied for national patent(ZL 2012 2 0676417.6) On 10th Dec 2012.

● C,D,A types.

● 0.5mm standard diameter.

● With 99%Al2O3 protection probe.

● Connectors and junction box are commonly used to connect the wires.

● To combat highly pressurized vacuum environment, our clients can bringing up the needs to customize integrated anti-high-pressure device on the thermocouple.

Tungsten rhenium ceramic thermocouple Recommend Using Temperature And Environment

Manual Welding

Automatic Welding

Insulation Testing

Laser Marking

Warehouse Managing

Thermocouple Assemble

Vacuum Leak Detection

Surface Polishing
