Name: China Customized Tungsten Rhenium Thermocouple W Tube Manufacturers Factory - Good Price
Brand: Duchin
SKU: 233829717

Products Description

Tungste rhenium thermocouple W tube is currently the highest temperature-measuring thermocouple. Its major usage is to measure temperature in vacuum, hydrogen, and inert atmosphere. The maximum measuring temperature reaches 2500℃. There are C, D, and A types have been specified. Our tungsten rhenium thermocouple W tube are made of specialized tungsten protective tubes which are filled with insulators, and assembled together under a vacuum or protective atmosphere with a seal.

Product Name	Tungsten rhenium thermocouple W tube
Thermoelement	C(Wre5/26),D(Wre3/25),A(Wre5/20)
Type	Simple or duplex type
Thermoelement diameter	φ0.5
Grade	0.5%,1.0%
Temperature	2100℃
Length	Specify total length and immersion length
Diameter	Specify OD
Tube	W(Tungsten) Tube
Insulators	HfO2

Technical characteristics

● Connectors and junction box are commonly used to connect the wires.

● To combat highly pressurized vacuum environment, our clients can bringing up the needs to customize integrated anti-high-pressure device on the thermocouple.

● Tungsten tube with high temperature resistance and corrosion resistance properties.

● Test calibration: It can only been tested or calibrated in vacuum or inert atmosphere, the specified max calibration temperature is 1700℃.

Tungsten rhenium thermocouple W tube Recommend Using Temperature And Environment

Protection tube	Tube OD	Insulators	Max.Temp℃	Application
W	Φ6,8	HfO2	2200	Vacuum,Air

Duchin is one of the earliest companies in China that developed tungsten-rhenium thermocouples. We have 10-ish industry-leading patents,besides the market share of this product is at the forefront of the nation, and has been evaluated as 'China Instrument Extrodinar' by China Instrument and Control Society, and has also earned the "Chongqing Famous Brand Product" title.
